GJTRACKER, TRACKER, SPACE and CALL3.TXT

GJTRACKER ANTENNA TRACKING PROGRAM FOR WINDOWS

The TRACKER program was re-written in October 2008 using Visual Basic 6.0 for use with Windows operating systems. Complete user instructions and associated GJTRACKER files are included in this zip file. GJTRACKER was written to be compatible with WSJT. The current version is 3.0.

SPACE

YAGI ANTENNA ARRAY SPACE/CLEARANCE PLANNING PROGRAM FOR DOS ENVIRONMENTS
(or in a DOS WINDOW under WINDOWS)

SPACE is a simple program that can be used to determine the approximate spatial clearance parameters of an array comprising any number of yagis, stacked vertically and/or horizontally. Front and Rear TURNING RADIUS as well as front and rear CLEARANCE HEIGHT, and minimum GROUND CLEARANCE are calculated as the array is elevated from 0 to 90 degrees. This old program is certainly far from high tech but has proven itself very handy in planning new towers and arrays, and in locating them properly in tight surroundings.

SPACE is also now available as an EXCEL program.

WSJT "CALL3.TXT" FILE

VHF DATABASE FOR USE WITH WSJT VERSION 4.9.2 AND LATER

Click here to download the zipped file for CALL3.TXT. CALL3.TXT is used by the WSJT applications and the current version of GJTRACKER to automatically enter the other station's grid locator. In addition to including location information for many VHF stations, it includes all known 6m EME stations. Information on this file follows:

CALL3.TXT
       THIS FILE WAS CONVERTED FROM CALLSIGN.TXT BY W7GJ FOR USE WITH CURRENT GJTRACKER
       AND WSJT (AFTER VERSION 4.9.2) PROGRAMS. IT WAS LAST UPDATED JANUARY 27, 2005.

IT COMBINES DATA FROM:
       AA1YN'S VHF AND UP REGISTRY
       DL8EBW'S VHF and MS/WSJT DATABASE
       DL4EBY'S 432 AND UP EME DIRECTORY
       W5LBT'S EME DIRECTORY
       CENTRAL STATES VHF SOCIETYTHE NEW COMMA DELIMITED CALL3.TXT RECORD FORMAT IS:        CALLSIGN, LOCATOR, EME FLAG, (these first three fields are used by WSJT)        plus optional fields:                STATE, FIRST NAME, EMAIL ADDRESS, NOTES, REVISION DATE             NOTES: WSJT requires that the Last Record of the file must be as shown below:         ZZZZZZ,End-Of-Callsign-Database

In addition to being very useful for use with WSJT modes, it is used in the most recent version of GJTRACKER moontracking program. It is in a text file format so you can correct/add/modify your personal version, using a text editor such as WORDPAD, or other types of database programs (PC File, EXCEL, etc.). Since this data base is a consolidation of information from other sources, no guarantee is offered regarding the accuracy of the information in this database.

You can also obtain program WsjtMerge.zip from K2TXB, to combine various versions of CALL3.TXT. Be sure to select the W7GJ format if you want to preserve all the data fields in the CALL3.TXT file from this site.

This page last updated on 17 February, 2016
